Cooler Master MWE Bronze 650 V3 230V power supply unit 650 W 24-pin ATX ATX Black
- In Stock
- 82.18€
- Ex Tax: 67.36€
- Brand: COL
- Model: 4719512145227
- Product Code: MPE-6501-ACABW-3BEU
- Availability: 2 pcs
- ID: 333138
Fast delivery
| Main | |
| 80 PLUS certification | 80 PLUS Bronze |
| AC input frequency | 50/60 Hz |
| AC input voltage | 200 - 240 V |
| ATX version | 3.1 |
| Bearing technology | HDB |
| Cabling type | Non-Modular |
| Combined power (+12V) | 648 W |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 3.6 W |
| Compliance certificates | RCM, BIS, EAC, RoHS, CE, China Compulsory Certification (CCC), UKCA, Federal Communications Commission (FCC) |
| Cooling type | Active |
| Depth | 140 mm |
| Efficiency | 88% |
| EPS cable length | 67 cm |
| EPS power connector (4+4 pin) | Yes |
| EPS power connector (8-pin) | Yes |
| Fan diameter | 12 cm |
| Hazard pictogram(s) | GHS07: Harmful, GHS02: Flammable, GHS09: Environmental hazard |
| Height | 86 mm |
| Hold time | 16 ms |
| Input current | 5 A |
| Master (outer) case height | 215 mm |
| Master (outer) case length | 570 mm |
| Master (outer) case width | 260 mm |
| Master (outer) cases per pallet (air) | 32 pc(s) |
| Max output current (+12V) | 54 A |
| Max output current (+3.3V) | 19 A |
| Max output current (+5V) | 19 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Mean time between failures (MTBF) | 100000 h |
| Motherboard power cable length | 50 cm |
| Motherboard power connector | 24-pin ATX |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 6 |
| Operating temperature (T-T) | 0 - 40 °C |
| package depth | 245 mm |
| package height | 110 mm |
| package weight | 2.05 kg |
| package width | 190 mm |
| PCI Express power cable length | 62 cm |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power cable length | 400 mm, 550, 700 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Power Factor Correction (PFC) type | Active |
| Power Good signal delay range | 100 - 150 ms |
| Power protection features | Short circuit, Over voltage, Under voltage, Over power, Overheating |
| Power supply unit (PSU) form factor | ATX |
| product colour | Black |
| Products per master (outer) case | 5 pc(s) |
| Purpose | PC/Server |
| SATA power cable length | 400 mm, 550, 700 mm |
| Total power | 650 W |
| weight | 1.65 kg |
| Width | 150 mm |
