Power supply Endorfy Elementum E5 (EY7A001) 550 W
- In Stock
- 68.72€
- Ex Tax: 56.33€
- Brand: END
- Model: 5903018666105
- Product Code: EY7A001
- Availability: 10 pcs
- ID: 338604
Fast delivery
| Main | |
| 80 PLUS certification | 80 PLUS |
| AC input frequency | 50 - 60 Hz |
| Cooling type | Active |
| Depth | 140 mm |
| DFU / User manual | Y |
| EPS power connector (4+4 pin) | Yes |
| Fan diameter | 12 cm |
| Fan location | Top |
| Hazard pictogram(s) | GHS09: Environmental hazard, GHS07: Harmful, GHS02: Flammable |
| Height | 87 mm |
| Length of EPS power connectors (4+4 pin) | 70 cm |
| Length of PCI Express power cable (6-pin) | 460 mm |
| Max output current (+12V) | 41 A |
| Max output current (+3.3V) | 18 A |
| Max output current (+5V) | 18 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.3 A |
| Motherboard power cable length | 45 cm |
| Motherboard power connector | 20+4 pin ATX |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 4 |
| On/off switch | Yes |
| PCI Express power cable length | 46 cm |
| PCI Express power connectors (6+2 pin) | 1 |
| PCI Express power connectors (6-pin) | 1 |
| Peripheral (Molex) power cable length | 555 mm, 410 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Power connector 16 PIN PCIe GEN5 | No |
| Power connector length 16 PIN PCIe GEN5 | Not applicable |
| Power Factor Correction (PFC) type | Active |
| Power protection features | OVP (overvoltage protection), SCP (short circuit protection), UVP (undervoltage protection), OPP (overload protection), SIP (surge and shock protection) |
| Power supply unit (PSU) form factor | ATX |
| product colour | Black |
| SATA power cable length | 555 mm, 410 mm, 700 mm |
| Total power | 550 W |
| Width | 150 mm |
