| ATX Power connector (24-pin) |
Yes |
| audio chip |
Realtek ALC897 |
| Audio output channels |
7.1 channels |
| BIOS type |
UEFI AMI |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| Cables included |
SATA |
| Compatible processor series |
Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5 |
| CPU fan connector |
Yes |
| Depth |
244 mm |
| DisplayPort version |
1.4 |
| DisplayPorts quantity |
1 |
| ECC сompatibility |
Non-ECC |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Front panel audio connector |
Yes |
| HDMI ports quantity |
1 |
| LAN controller |
Dragon RTL8125BG |
| line-in |
Yes |
| Maximum internal memory |
128 GB |
| Maximum number of SMP processors |
1 |
| memory channels |
Dual-channel |
| Memory slots type |
DIMM |
| microphone in |
Yes |
| motherboard chipset |
Intel B760 |
| Motherboard chipset family |
Intel |
| Motherboard form factor |
micro ATX |
| Number of M.2 (M) slots |
1 |
| Number of memory slots |
4 |
| Number of SATA III connectors |
4 |
| PCI Express x1 (Gen 4.x) slots |
1 |
| PCI Express x16 (Gen 5.x) slots |
1 |
| PCI Express x4 (Gen 1.x) slots |
1 |
| processor manufacturer |
Intel |
| processor socket |
LGA 1700 |
| PS/2 ports quantity |
1 |
| RGB LED pin header |
Yes |
| Supported memory types |
DDR5-SDRAM |
| Supported storage drive interfaces |
M.2, SATA III |
| Supported storage drive types |
HDD & SSD |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| TPM connector |
Yes |
| Unbuffered memory |
Yes |
| USB 2.0 connectors |
2 |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Wi-Fi standards |
Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 6E (802.11ax), 802.11b, 802.11a |
| Width |
244 mm |
| WiFi |
Yes |
| Windows operating systems supported |
Windows 11 x64, Windows 10 x64 |
