Antenna |
Yes |
Antenna design |
Internal |
Antenna direction type |
Omni-directional |
Compliance certificates |
Federal Communications Commission (FCC), RoHS, CE |
Component for |
PC/Laptop |
Connectivity technology |
Wired |
Depth |
19.7 mm |
Frequency range |
2.4 - 5 GHz |
Harmonized System (HS) code |
85176990 |
Height |
10.3 mm |
Host interface |
USB |
Interface |
WLAN |
Internal |
No |
LED indicators |
Status |
Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.13 High Sierra, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks |
Maximum data transfer rate |
867 Mbit/s |
Modulation |
64-QAM, OFDM, 16-QAM, CCK, DBPSK, DQPSK, 256-QAM |
MU-MIMO |
Yes |
Networking standards |
IEEE 802.11ac, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b |
Operating modes |
Infrastructure mode |
Operating relative humidity (H-H) |
10 - 90% |
Operating temperature (T-T) |
0 - 40 °C |
package depth |
128 mm |
package height |
30 mm |
package weight |
90 g |
package width |
138 mm |
product colour |
Black |
Quick installation guide |
Yes |
Resource CD |
Yes |
Security algorithms |
WPA-PSK, 64-bit WEP, WPA2, 128-bit WEP, WPA2-PSK, WPA |
Storage relative humidity (H-H) |
5 - 90% |
storage temperature (T-T) |
-40 - 70 °C |
Sustainability compliance |
Yes |
Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
Transmitting power (CE) |
23 dBm |
Transmitting power (FCC) |
23 dBm |
USB ports quantity |
1 |
USB powered |
Yes |
USB version |
3.2 Gen 1 (3.1 Gen 1) |
Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
Wi-Fi standards |
802.11b, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 4 (802.11n), 802.11g |
Width |
40.5 mm |
WiFi |
Yes |
Windows operating systems supported |
Windows 7 Home Basic, Windows 7 Ultimate, Windows XP Professional x64, Windows 10 Home x64, Windows 8, Windows 10, Windows 10 IOT Core, Windows 8.1 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 10 Enterprise x64, Windows 10 Pro x64, Windows 8 x64, Windows 10 Education, Windows XP Professional, Windows 8.1, Windows 7 Ultimate x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows XP Home, Windows 10 Home, Windows 7 Starter x64, Windows 7 Professional x64, Windows 8 Pro x64, Windows 8.1 Pro, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 Education x64, Windows XP Home x64, Windows 7 Home Premium x64, Windows 7 x64, Windows 8 Enterprise, Windows 11 Enterprise x64, Windows 7, Windows 10 IoT Enterprise, Windows 11 x64, Windows 10 x64, Windows 7 Enterprise x64, Windows 11, Windows 11 Home, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows XP, Windows 11 Enterprise, Windows 11 Pro |
WLAN data transfer rates supported |
400, 11, 54, 867 Mbit/s, 300 |
