2.4 GHz |
Yes |
5 GHz |
No |
6 GHz |
No |
AC adapter included |
Yes |
Access Control List (ACL) |
Yes |
Antenna gain level (max) |
4 dBi |
antenna type |
Internal |
Antennas quantity |
2 |
Automatic channel selection |
Yes |
Depth |
172.3 mm |
Ethernet LAN (RJ-45) ports |
1 |
Ethernet LAN data rates |
10, 100 |
Frequency band |
2.4 - 2.4835 GHz |
Harmonized System (HS) code |
85176990 |
Height |
29.5 mm |
LED indicators |
Yes |
MAC address filtering |
Yes |
Maximum data transfer rate |
300 Mbit/s |
Maximum data transfer rate (2.4 GHz) |
300 Mbit/s |
Mounting kit |
Yes |
Networking standards |
IEEE 802.11g, IEEE 802.11n, IEEE 802.11b |
Number of products included |
1 pc(s) |
Number of SSID supported |
8 |
On/off switch |
Yes |
Operating relative humidity (H-H) |
10 - 90% |
Operating temperature (T-T) |
0 - 40 °C |
Output current |
0.6 A |
Output voltage |
9 V |
package depth |
246 mm |
package height |
69 mm |
package weight |
600 g |
package width |
268 mm |
Placement |
Ceiling, Wall |
Power consumption (typical) |
2.8 W |
Power over Ethernet (PoE) |
Yes |
product colour |
White |
Quality of Service (QoS) support |
Yes |
Rate limiting |
Yes |
Reset button |
Yes |
Security algorithms |
HTTPS, SSH, 64-bit WEP, WPA2-Enterprise, WPA-PSK, 128-bit WEP, SNMP, 152-bit WEP, WPA, WPA2-PSK |
Storage relative humidity (H-H) |
5 - 90% |
storage temperature (T-T) |
-40 - 70 °C |
Syslog |
Yes |
System status alarm |
Y |
WAN connection |
Ethernet (RJ-45), Wi-Fi |
Web-based management |
Yes |
Wi-Fi Multimedia (WMM)/(WME) |
Yes |
Width |
189.4 mm |
Wireless isolation |
Yes |
