| 2.4 GHz |
Yes |
| 5 GHz |
No |
| 6 GHz |
No |
| Access Control List (ACL) |
Yes |
| Antenna direction type |
Omni-directional |
| Antenna features |
Detachable antenna |
| Antenna gain level (max) |
3 dBi |
| Antenna included |
Yes |
| antenna type |
External |
| Antennas quantity |
2 |
| Automatic channel selection |
Yes |
| Cables included |
AC |
| Compliance certificates |
Federal Communications Commission (FCC), RoHS, CE |
| Depth |
46 mm |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10, 100 |
| Frequency band |
2.4 GHz |
| Height |
27 mm |
| International Protection (IP) code |
IP65 |
| LED indicators |
Power |
| MAC address filtering |
Yes |
| Management protocols |
HTTP/HTTPS, SNMP, Telnet |
| Maximum data transfer rate |
300 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
300 Mbit/s |
| Mounting kit |
Yes |
| Networking standards |
IEEE 802.11g, IEEE 802.11n, IEEE 802.11b |
| Number of SSID supported |
8 |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
-30 - 65 °C |
| Output current |
0.6 A |
| Output voltage |
24 V |
| package depth |
270 mm |
| package height |
100 mm |
| Package type |
Box |
| package weight |
620 g |
| package width |
140 mm |
| Placement |
Pole, Wall |
| PoE adapter included |
Yes |
| Power consumption (max) |
3.12 W |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
Passive PoE |
| product colour |
White |
| Quality of Service (QoS) support |
Yes |
| Quantity per pack |
1 pc(s) |
| Rate limiting |
Yes |
| Remote Authentication Dial-In User Service (RADIUS) |
Yes |
| Reset button |
Yes |
| Security algorithms |
WPA2-PSK, WPA-Enterprise, WPA-PSK, WPA2-Enterprise |
| Service Set Identifier (SSID) features |
Multiple SSIDs |
| Storage relative humidity (H-H) |
5 - 90% |
| storage temperature (T-T) |
-40 - 70 °C |
| Sustainability compliance |
Yes |
| Syslog |
Yes |
| Transmitting power (CE) |
20 dBm |
| Transmitting power (FCC) |
22 dBm |
| Virtual LAN features |
VLAN mapping, Tagged VLAN |
| VLAN support |
Yes |
| Web-based management |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Width |
216 mm |
| Wireless isolation |
Yes |
