| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Buffer size |
128 KB |
| Depth |
100 mm |
| DHCP features |
DHCP client |
| DoS attack prevention |
Yes |
| Flow control support |
Yes |
| Harmonized System (HS) code |
85176990 |
| Height |
27 mm |
| IGMP snooping |
Yes |
| Jumbo frames |
9000 |
| Jumbo frames support |
Yes |
| LED indicators |
Link, Speed, System, Activity, Power |
| Link aggregation |
No |
| Loop protection |
Yes |
| MAC address table |
8000 entries |
| Master (outer) case gross weight |
10.2 kg |
| Master (outer) case height |
280 mm |
| Master (outer) case length |
497 mm |
| Master (outer) case width |
344 mm |
| Mean time between failures (MTBF) |
2531294 h |
| Networking standards |
IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az |
| Non-operating altitude |
0 - 3000 m |
| Number of VLANs |
64 |
| operating altitude |
0 - 3000 m |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 50 °C |
| package depth |
237 mm |
| package height |
61 mm |
| Package type |
Box |
| package weight |
600 g |
| package width |
153 mm |
| password protection |
Yes |
| Port mirroring |
Yes |
| Power over Ethernet (PoE) |
No |
| product colour |
Black |
| Products per master (outer) case |
15 pc(s) |
| Quality of Service (QoS) support |
Yes |
| Rack mounting |
No |
| Rate limiting |
Yes |
| Storage relative humidity (H-H) |
0 - 95% |
| storage temperature (T-T) |
-20 - 70 °C |
| Store-and-forward |
Yes |
| Switch type |
Managed |
| Switching capacity |
10 Gbit/s |
| Virtual Cable Test (VCT) |
Yes |
| Virtual LAN features |
Port-based VLAN, Tagged VLAN |
| VLAN support |
Yes |
| Web-based management |
Yes |
| weight |
250 g |
| Width |
94 mm |
