Basic switching RJ-45 Ethernet ports quantity |
5 |
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
Buffer size |
128 KB |
Depth |
100 mm |
DHCP features |
DHCP client |
DoS attack prevention |
Yes |
Flow control support |
Yes |
Harmonized System (HS) code |
85176990 |
Height |
27 mm |
IGMP snooping |
Yes |
Jumbo frames |
9000 |
Jumbo frames support |
Yes |
LED indicators |
Link, Speed, System, Activity, Power |
Link aggregation |
No |
Loop protection |
Yes |
MAC address table |
8000 entries |
Master (outer) case gross weight |
10.2 kg |
Master (outer) case height |
280 mm |
Master (outer) case length |
497 mm |
Master (outer) case width |
344 mm |
Mean time between failures (MTBF) |
2531294 h |
Networking standards |
IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az |
Non-operating altitude |
0 - 3000 m |
Number of VLANs |
64 |
operating altitude |
0 - 3000 m |
Operating relative humidity (H-H) |
0 - 90% |
Operating temperature (T-T) |
0 - 50 °C |
package depth |
237 mm |
package height |
61 mm |
Package type |
Box |
package weight |
600 g |
package width |
153 mm |
password protection |
Yes |
Port mirroring |
Yes |
Power over Ethernet (PoE) |
No |
product colour |
Black |
Products per master (outer) case |
15 pc(s) |
Quality of Service (QoS) support |
Yes |
Rack mounting |
No |
Rate limiting |
Yes |
Storage relative humidity (H-H) |
0 - 95% |
storage temperature (T-T) |
-20 - 70 °C |
Store-and-forward |
Yes |
Switch type |
Managed |
Switching capacity |
10 Gbit/s |
Virtual Cable Test (VCT) |
Yes |
Virtual LAN features |
Port-based VLAN, Tagged VLAN |
VLAN support |
Yes |
Web-based management |
Yes |
weight |
250 g |
Width |
94 mm |
