| 10G support |
No |
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
220 - 240 V |
| Auto MDI/MDI-X |
Yes |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Broadcast storm control |
Yes |
| Cables included |
AC |
| Copper ethernet cabling technology |
100BASE-TX, 10BASE-T, 1000BASE-T |
| Depth |
104 mm |
| Electromagnetic compatibility |
LVD EN60950-1, BSMI CNS14336-1 |
| Flow control support |
Yes |
| Forwarding rate |
11.9 Mpps |
| Full duplex |
Yes |
| Gigabit Ethernet (copper) ports quantity |
8 |
| Harmonized System (HS) code |
85176990 |
| Heat dissipation |
16.03 BTU/h |
| Height |
27 mm |
| IGMP snooping |
Yes |
| Jumbo frames |
9000 |
| Jumbo frames support |
Yes |
| LED indicators |
Yes |
| MAC address filtering |
Yes |
| MAC address table |
8000 entries |
| Management protocols |
SNMP v1,v2,v3, RMON (1,2,3,9) |
| Manual |
Yes |
| Mean time between failures (MTBF) |
1144461 h |
| MIB support |
RFC 1213 MIB II, RFC 2819, RFC 1215, RFC 1493 |
| Multicast support |
Yes |
| Networking standards |
IEEE 802.3ad, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p |
| Number of VLANs |
8 |
| Operating relative humidity (H-H) |
10 - 95% |
| Operating temperature (T-T) |
0 - 40 °C |
| package depth |
227 mm |
| package height |
64 mm |
| package weight |
1.1 kg |
| package width |
302 mm |
| Packet buffer memory |
0.525 MB |
| Power connector |
AC-in jack |
| Power consumption (max) |
4.7 W |
| Power over Ethernet (PoE) |
No |
| Power source |
AC |
| product colour |
Black |
| Quality of Service (QoS) support |
Yes |
| Quick start guide |
Yes |
| Rate limiting |
Yes |
| SSH/SSL support |
Yes |
| Storage relative humidity (H-H) |
10 - 95% |
| storage temperature (T-T) |
-40 - 70 °C |
| Switch layer |
L2 |
| Switch type |
Managed |
| Switching capacity |
16 Gbit/s |
| System event log |
Yes |
| User guide |
Yes |
| VLAN support |
Yes |
| Web-based management |
Yes |
| weight |
620 g |
| Width |
250 mm |
