Mainboard|ASROCK|LGA 1851 (Socket V1)|RAM DDR5-SDRAM|2xSlots|H810M-XGEN5WIFI

Laos olemas
106.44€
Maksudeta: 85.84€

Tootja: ASROCK
Mudel: 4711581493834
Tootekood: H810M-X GEN5 WIFI
Saadavus: 10 tk
ID: 400504

Kiire tarne

Tarnija

LV1 (1-3 päeva) - 10 tk

Kogus

Kirjeldus
Tehnilised andmed

CPU Intel , Socket LGA 1851 (Socket V1) , Series Intel Core Ultra (Series 2) , Supported memory types DDR5-SDRAM , 2xNumber of memory slots , Memory slots type DIMM , Supported storage drive interfaces SATA III,M.2

Peamine
Antenna included	Yes
ATX Power connector (24-pin)	Yes
Audio output channels	7.1 channels
BIOS memory size	256 Mbit
BIOS type	UEFI AMI
Bluetooth	Yes
Bluetoothi versioon	5.3
CnCode	84733020
Compatible processor series	Intel Core Ultra (Series 2)
Component for	PC
CPU fan connector	Yes
DisplayPort version	1.4
DisplayPorts quantity	1
ECC сompatibility	Non-ECC
emaplaadi kiibistik	Intel H810
EPS power connector (8-pin)	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Etherneti LAN	Yes
Etherneti LAN (RJ-45) pordid	1
Front panel audio connector	Yes
HDCP	Yes
HDCP version	2.3
HDMI ports quantity	1
helikiip	Realtek ALC897
Kaablid kaasas	SATA
Kategooria kood	MBI
Kirjeldus	X Series motherboard offers a compact, high-value solution, balancing performance, versatility, and reliability for both professional and daily tasks. The ASRock X-Series motherboard provides a high-value solution, balancing performance and versatility within a compact form factor. It’s highly capable in handling a wide range of tasks, from professional productivity to everyday usage, striking an excellent balance between affordability, reliability, and efficiency. Power Phase Design Featuring sturdy components and completely smooth power delivery to the CPU, offering enhanced performance for gamers. Hyper M.2 Gen4 x4 Supports PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience. Aluminum Heatsink The first thing that catches the eye is the optimized Aluminum Heatsink Design. Heatsinks are crucial for efficient heat dissipation, especially during heavy workloads like gaming or productivity tasks. Motherboard that built with heatsinks can effectively manage thermal performance, hence ensure system stability and durability effortlessly. Wi-Fi 6 802.11ax Wi-Fi 6 (802.11ax) supports speeds of up to 2.4 Gbps and operates natively across both the 2.4 GHz and 5 GHz bands. It also delivers significantly improved bi-directional MU-MIMO support for more efficient multi-device connectivity. M.2 (KEY E) For WiFi Besides the onboard LAN port, users may also choose wireless connections by M.2 (Key E) slot. Dragon 2.5 Gb/s LAN The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you’ll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups. Front USB 3.2 Gen1 Type-C Front USB 3.2 Gen1 Type-C header delivers up to 5 Gbps data transfer rate and next generation reversible USB design to the front panel of computer case. POLYCHROME RGB This motherboard features onboard RGB headers and addressable RGB headers that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects. SignalRGB SignalRGB unifies your RGB devices, offering seamless customization, game-reactive effects, macro automation, and system monitoring. The official partnership empowers ASRock motherboards with advanced lighting control, enhances compatibility with a diverse range of RGB devices, and provides greater customization flexibility.
Laius	244 mm
LAN controller	Dragon RTL8125BG
line-in	Yes
M.2 (M) pilude arv	1
Maksimaalne sisemälu	128 GB
mälukanalid	Dual-channel
Memory slots type	DIMM
mikrofon sisse	Yes
Motherboard chipset family	Intel
Motherboard form factor	micro ATX
Müüja koduleht	https://www.asrock.com/MB/Intel/H810M-X%20Gen5%20WiFi/index.asp#Specification
Number of chassis fan connectors	1
Number of CPU fan connectors	1
Number of memory slots	2
Number of SATA III connectors	4
PCI Express x1 (Gen 4.x) slots	1
PCI Express x16 (Gen 5.x) slots	1
protsessori pesa	LGA 1851 (Socket V1)
protsessori tootja	Intel
RGB LED pin header	Yes
Sügavus	193 mm
Summary	Asrock H810M-X Gen5 WiFi. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: SATA III, M.2. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Dragon RTL8125BG, Top Wi-Fi standard: Wi-Fi 6 (802.11ax). Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel
Supported memory types	DDR5-SDRAM
Supported storage drive interfaces	SATA III,M.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
TPM connector	Yes
Üksuse kasti kõrgus	0.265
Üksuse kasti laius	0.06
Üksuse kasti pikkus	0.26
Unbuffered memory	Yes
Unit Calculated Volume	0.005111 cubm
Unit Calculated Weight	1.05 kg
Units per Pallet	0
Units per Shipping Box	10
USB 2.0 connectors	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) A-tüüpi portide arv	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
Wi-Fi standardid	802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)
wifi	Yes
Windows operating systems supported	Windows 11 x64
